November 24, 2020
Moment Capacity of Slabs with Base Reinforcement
In this video, the calculated moment capacity of a slab with base reinforcement, as well as the cover requirements for base reinforcement are reviewed.
With the adoption of ASCE 7-22, the concept of a multi-period response spectrum has been added to seismic design requirements. While this provides more accurate hazard representation, it also means engineers need to generate and input additional site-specific data. This quick workflow shows how to gather that data from the ASCE Hazard Tool and use it in RISA’s site parameters table for seismic load generation. Why This Matters for Engineers? Multi-period response spectra reflect more realistic ground motion characteristics and will increasingly be required as jurisdictions adopt ASCE 7-22. By pulling site-specific values directly from the ASCE Hazard Tool, engineers can ensure compliance and avoid unnecessary assumptions. The multi-period approach can result in higher or lower design forces depending on the building’s period and site class, but it always provides more accurate seismic representation than the traditional two-point method. Download the latest versions of RISA that supports ASCE 7-22 below. Step 1: Generate Multi-Period Spectrum Data Go to the ASCE Hazard Tool. Enter your project location (address, coordinates, or site description). Select ASCE 7-22 as the building code. Navigate to the seismic hazard results and download/export the Multi-Period Response Spectrum data. Step 2: Copy Data Points into RISA Open RISA…
Read More
In this video, the calculated moment capacity of a slab with base reinforcement, as well as the cover requirements for base reinforcement are reviewed.
