Aluminum Design Code Update - AA ADM1-2015
The new Aluminum ADM 2015 code has been added in RISA-3D v15.0. To select this code for your design, simply open the (Global) Model Settings and under the Codes tab select AA ADM1-15:
Rigid diaphragms in RISA-3D are a powerful way to model how floor systems distribute lateral loads. By forcing all connected nodes to move together in-plane, they effectively capture the stiffness of a concrete slab or diaphragm deck—often simplifying analysis without sacrificing accuracy. However, when rigid diaphragms are combined with sloping members, they can introduce unexpected behavior that changes how the structure resists loads—sometimes creating a hidden “tension tie” that doesn’t exist in the real system. When Rigid Diaphragms Alter the Model’s Behavior Consider a simple moment frame with sloped beams under gravity loads—common in pre-engineered metal buildings. Model 1: No rigid diaphragm applied Model 2: Identical frame, but with a rigid diaphragm located at the eaves When reviewing the strong-axis bending moments, column base reactions, and thrust forces: The first frame behaves as expected. The second frame (with the rigid diaphragm) shows reduced bending moments and smaller thrust reactions at the column bases. At first glance, this might seem like an improvement—but it’s actually unrealistic behavior caused by the diaphragm. Why It Happens: The “Hidden Tension Tie” In the model with the rigid diaphragm, the diaphragm prevents the eaves from moving apart under load. This effectively turns the diaphragm into…
Read More
The new Aluminum ADM 2015 code has been added in RISA-3D v15.0. To select this code for your design, simply open the (Global) Model Settings and under the Codes tab select AA ADM1-15:
The bending and axial code checks for single angles differ somewhat from other shape types, because single angles behave quite differently in bending and compression depending on how they are braced along their length.
RISA-3D can design the Cold Formed Steel face-to-face channel and track sections. You can also get design of a Cold Formed Steel tube shape in RISA-3D. The Shape Selection dialog will allow you to model the built-up sections by selecting “Face to Face” shown below.
The new CSA O86-14 code has been implemented in RISA-3D v15.0 and RISAFloor v11.0
RISA-3D now supports hot rolled steel design for the Canadian market according to CSA S16-14.
These include:
In RISA-3D, RISAFloor, and RISAFoundation the cursor now provides additional information regarding the cursor coordinates. As you move your cursor around on your screen, a box adjacent to your cursor will appear and populate with the coordinates of the cursor.
In the RISA-3D when you model a WT brace it exists at the member centroid, which means that no bending ends up in the brace due to the fact that the brace is actually eccentric to the braced frame.
Seismic Forces are generated automatically using seismic parameters R, SD1, and SDS in the Seismic Load Generator when using the Director to go from RISAFloor to RISA-3D or when inserting Seismic Loads on a rigid diaphragm in RISA-3D. Additionally, Seismic Load Combinations can be generated using...
