February 1, 2017
|
RISAFloor,
New,
Modeling
RISAFloor
v11
includes
the
ability
to
re-position
selected
elements
such
as
beams,
columns,
walls,
and
nodes
in
your
model.
On
the
Graphic
Editing
Toolbar,
click
on
the
Move
Selected
Items
button
to
open
the
Move
Selected
Items
dialog
box.
Move
by
Point
Location
option
allows
the
user
to
click
on
the
first
point
and
then
click
on
the
second
point
to
define
the
distance
to
move
the
selected
items.
In
the
example
below,
the
Move
by
Point
Location
option
is
selected.
With
N4
highlighted,
the
first
click
is
on
N4
and
then
the
second
click
is
on
project
grid
line
C3,
which
modes
the
wall
panels
associated
with
that
end
node.
The
beam
ends
did
not
move
because
their
end
nodes
were
not
selected.
In
this
case,
a
good
option
is
to
use
the
Trim
and
Extend
tools
to
clean
up
any
framing
discontinuities.
Move
Distance
lets
you
to
enter
in
the
increments
for
the
distance
entered
in
the
X
and
Y
directions.
For
example
in
the
below
image,
the
selected
beam
and
column
are
moved
by
entering
in
a
distance
of
10’
in
the
X
direction.
When
elements
such
as
beams
and
walls
are
moved,
the
end
joints
associated…
