Viewing column information graphically in RISAFloor

RISAFloor column results are available in the results spreadsheets, but you may not be aware that you can also graphically review the input and results of columns. To do this you need to customize your toolbar, which is an option available in the Tools menu:

Floor Graphic Column Results 01 300x107 2x

Add the Column Input and Column Result buttons to your toolbar:

Floor Graphic Column Results 02

The column input and column results buttons will now be available on your toolbar. Click the black drop down arrow to see which sizes were chosen during the member optimization (Design Results) or what the Code Check values are:

Floor Graphic Column Results 03 Floor Graphic Column Results 04
