How to Add a Drop Panel

In RISAFloor ES, you can quickly thicken the slab in the column strip area with the Drop Panel tool. The column strip is typically the area of highest demand so increasing the thickness may help optimize the concrete usage.

After the support lines are drawn, you can modify columns strip depth by clicking on the Support Line icon at the left side of the screen.

Drop Panel1

Next select the Modify Properties tab, and click “Use?” in the Drop Panel Thickness selection. The thickness is defined by the additional thickness below the slab.

Drop Panel2

Once you select the support line, it will be outlined in black to indicate that it’s modified.

Drop Panel3

The Full Model view shows the additional thickened slab in a rendered view.

Drop Panel4
