June 15, 2023

New Release: RISACalc v4.1

RISA is pleased to announce the latest update of the web based software RISACalc. This version of RISACalc has added the following enhancements!

Hot Rolled Double Channels for Beams & Columns
Wind Load Generator (MWFRS)

The latest update to RISACalc includes wind load generation for the Main Wind Force Resisting System (MWFRS) with ASCE 7-16 and ASCE 7-10. Edit your wind load properties and site parameters in the easy to use tabs. Also update the building geometry to show in the graphic display of the Wind Load Generator. You can open the detailed report to view your results!

WindGenerator_RISACA

Check it out!

For more information on this release, see our release notes.

RISACalc

Tags: New, RISACalc
