September 7, 2022
|
RISA-3D,
RISAFloor,
New,
Link Utilities,
Autodesk Revit,
RISA-Revit Link
RISA
is
pleased
to
announce
the
release
of
the
latest
RISA-Revit
Link
which
includes
compatibility
with
Revit
2023.
The
RISA-Revit
Link
v23.0
allows
seamless
integration
between
RISAFloor,
RISA-3D,
and
Autodesk
Revit.
This
version
of
the
link
also
includes
updates
to
the
round-tripping
process
due
to
Revit’s
new
workflow
for
structural
analysis.
The
RISA-Revit
link
utilizes
Revit’s
analytical
model
to
transfer
members
between
the
programs.
However,
with
the
release
of
the
latest
iteration
of
the
workflow,
Revit
no
longer
automatically
creates
an
analytical
model
when
drawing
physical
members.
Instead
Revit
2023
introduced
a
new
tool
called
"Analytical
Automation"
to
help
convert
the
physical
members
to
analytical
members.
This
automation
works
for
most
physical
member
element
types
in
Revit.
But
for
members,
such
as
foundation
elements,
that
are
not
converted
during
Revit's
"Analytical
Automation",
the
user
has
to
manually
generate
the
analytical
member.
As
always,
users
must
create
the
analytical
model
in
Revit
2023
before
using
the
RISA-Revit
link
to
transfer
model
information
to
RISA-3D
or
RISAFloor.
Updated
Integration
Procedure
To
transfer
models
from
Revit
2023
into
RISA,
generate
the
analytical
model
by
selecting
the
Analyze
tab
then
Analytical
Automation
in
Revit
2023.
A
separate
window
will
populate
to
start
generating
the…
